Window: Replication Strategy
[Created: 19/06/2003 - Updated: 15/01/2024 ]
Description: Maintain Data Replication Strategy
Help: The Data Replication Strategy determines which tables and how they are replicated. Note that the migration does not synchronize Application Dictionary items.
Tab: Replication Strategy
[Created: 19/06/2003 - Updated: 15/01/2024 ]
Description: Data Replication Strategy
Help: The Data Replication Strategy determines which tables and how they are replicated. Note that the migration does not synchronize Application Dictionary items.
Tab Level: 0
Table 10: Replication Strategy - Fields
Table: Report Parameters
| Name | Description | Help | Technical Info |
|---|---|---|---|
| Tenant | Tenant for this installation. | A Tenant is a company or a legal entity. You cannot share data between Tenants. | ad_replicationstrategy.AD_Client_ID numeric(10) Table Direct |
| Organization | Organizational entity within tenant | An organization is a unit of your tenant or legal entity - examples are store, department. You can share data between organizations. | ad_replicationstrategy.AD_Org_ID numeric(10) Table Direct |
| Search Key | Search key for the record in the format required - must be unique | A search key allows you a fast method of finding a particular record.If you leave the search key empty, the system automatically creates a numeric number. The document sequence used for this fallback number is defined in the "Maintain Sequence" window with the name "DocumentNo_", where TableName is the actual name of the table (e.g. C_Order). | ad_replicationstrategy.Value character varying(40) String |
| Name | Alphanumeric identifier of the entity | The name of an entity (record) is used as an default search option in addition to the search key. The name is up to 60 characters in length. | ad_replicationstrategy.Name character varying(60) String |
| Description | Optional short description of the record | A description is limited to 255 characters. | ad_replicationstrategy.Description character varying(255) String |
| Comment/Help | Comment or Hint | The Help field contains a hint, comment or help about the use of this item. | ad_replicationstrategy.Help character varying(2000) Text |
| Active | The record is active in the system | There are two methods of making records unavailable in the system: One is to delete the record, the other is to de-activate the record. A de-activated record is not available for selection, but available for reports.There are two reasons for de-activating and not deleting records:(1) The system requires the record for audit purposes.(2) The record is referenced by other records. E.g., you cannot delete a Business Partner, if there are invoices for this partner record existing. You de-activate the Business Partner and prevent that this record is used for future entries. | ad_replicationstrategy.IsActive character(1) Yes-No |
| Entity Type | Dictionary Entity Type; Determines ownership and synchronization | The Entity Types "Dictionary", "iDempiere" and "Application" might be automatically synchronized and customizations deleted or overwritten. For customizations, copy the entity and select "User"! | ad_replicationstrategy.EntityType character varying(40) Table |
| Export Processor | ad_replicationstrategy.EXP_Processor_ID numeric(10) Table Direct |
Tab: Replication Table
[Created: 19/06/2003 - Updated: 05/03/2008 ]
Description: Data Replication Strategy Table Info
Help: Determines how the table is replicated. You have full access to Local tables, Reference tables are on Remote systems and are read-only. The data of Merge tables on Remote systems is copied to the central system.
Tab Level: 1
Table 20: Replication Table - Fields
Table: Report Parameters
| Name | Description | Help | Technical Info |
|---|---|---|---|
| Tenant | Tenant for this installation. | A Tenant is a company or a legal entity. You cannot share data between Tenants. | ad_replicationtable.AD_Client_ID numeric(10) Table Direct |
| Organization | Organizational entity within tenant | An organization is a unit of your tenant or legal entity - examples are store, department. You can share data between organizations. | ad_replicationtable.AD_Org_ID numeric(10) Table Direct |
| Replication Strategy | Data Replication Strategy | The Data Replication Strategy determines what and how tables are replicated | ad_replicationtable.AD_ReplicationStrategy_ID numeric(10) Table Direct |
| Table | Database Table information | The Database Table provides the information of the table definition | ad_replicationtable.AD_Table_ID numeric(10) Table Direct |
| Active | The record is active in the system | There are two methods of making records unavailable in the system: One is to delete the record, the other is to de-activate the record. A de-activated record is not available for selection, but available for reports.There are two reasons for de-activating and not deleting records:(1) The system requires the record for audit purposes.(2) The record is referenced by other records. E.g., you cannot delete a Business Partner, if there are invoices for this partner record existing. You de-activate the Business Partner and prevent that this record is used for future entries. | ad_replicationtable.IsActive character(1) Yes-No |
| Description | Optional short description of the record | A description is limited to 255 characters. | ad_replicationtable.Description character varying(255) String |
| Replication Type | Type of Data Replication | The Type of data Replication determines the direction of the data replication. Reference means that the data in this system is read only -> Local means that the data in this system is not replicated to other systems - Merge means that the data in this system is synchronized with the other system | ad_replicationtable.ReplicationType character(1) List |
| Entity Type | Dictionary Entity Type; Determines ownership and synchronization | The Entity Types "Dictionary", "iDempiere" and "Application" might be automatically synchronized and customizations deleted or overwritten. For customizations, copy the entity and select "User"! | ad_replicationtable.EntityType character varying(40) Table |
Tab: Replication Document
[Created: 05/03/2008 - Updated: 05/03/2008 ]
Description:
Help:
Tab Level: 1
Table 30: Replication Document - Fields
Table: Report Parameters
| Name | Description | Help | Technical Info |
|---|---|---|---|
| Tenant | Tenant for this installation. | A Tenant is a company or a legal entity. You cannot share data between Tenants. | ad_replicationdocument.AD_Client_ID numeric(10) Table Direct |
| Organization | Organizational entity within tenant | An organization is a unit of your tenant or legal entity - examples are store, department. You can share data between organizations. | ad_replicationdocument.AD_Org_ID numeric(10) Table Direct |
| Replication Strategy | Data Replication Strategy | The Data Replication Strategy determines what and how tables are replicated | ad_replicationdocument.AD_ReplicationStrategy_ID numeric(10) ID |
| Document Type | Document type or rules | The Document Type determines document sequence and processing rules | ad_replicationdocument.C_DocType_ID numeric(10) Table Direct |
| Table | Database Table information | The Database Table provides the information of the table definition | ad_replicationdocument.AD_Table_ID numeric(10) Search |
| Active | The record is active in the system | There are two methods of making records unavailable in the system: One is to delete the record, the other is to de-activate the record. A de-activated record is not available for selection, but available for reports.There are two reasons for de-activating and not deleting records:(1) The system requires the record for audit purposes.(2) The record is referenced by other records. E.g., you cannot delete a Business Partner, if there are invoices for this partner record existing. You de-activate the Business Partner and prevent that this record is used for future entries. | ad_replicationdocument.IsActive character(1) Yes-No |
| Description | Optional short description of the record | A description is limited to 255 characters. | ad_replicationdocument.Description character varying(255) String |
| Replication Type | Type of Data Replication | The Type of data Replication determines the direction of the data replication. Reference means that the data in this system is read only -> Local means that the data in this system is not replicated to other systems - Merge means that the data in this system is synchronized with the other system | ad_replicationdocument.ReplicationType character(1) List |
